tnt 2025-10-01 9:00 p.m.
The specs for diffusion / poly have specs for both salicided and non-salicided version. Can anyone confirm the default is that those will receive salicide except where the SAB layer is drawn ? ( I'm kind of guessing SAB is "SAlicide Block" )
Avatar
Avatar
tnt
The specs for diffusion / poly have specs for both salicided and non-salicided version. Can anyone confirm the default is that those will receive salicide except where the SAB layer is drawn ? ( I'm kind of guessing SAB is "SAlicide Block" )
htamas 2025-10-01 9:51 p.m.
Yes, it's salicide block: https://gf180mcu-pdk.readthedocs.io/en/latest/physical_verification/design_manual/drm_04_3.html
Avatar
Tim 'mithro' Ansell 2025-10-01 10:39 p.m.
@Tim Edwards - I believe @htamas is correct here?
Avatar
Tim Edwards 2025-10-01 10:41 p.m.
Yes.
Avatar
tnt 2025-10-02 5:24 a.m.
Thanks
