algofoogle (Anton Maurovic) 2025-09-11 4:48 a.m.
I’m only loosely thinking about this at the moment, as part of a personal interest/learning project. As such I don’t have much budget. Here are some initial thoughts though…
  • maybe 1mm2 area
  • Up to 30 digital IOs (or some mix of I, O, and IO)
  • probably 4 analog pins
  • I need bonding… COB or packaged parts
  • caravel is optional for me
Avatar
algofoogle (Anton Maurovic) 2025-09-11 1:52 p.m.
@Essen this was meant to be a reply to you, sorry
Avatar
Essen 2025-09-13 1:04 p.m.
No worries. 🙂 Nice, thanks for the list. Let's see if we can get a few more people on board to help bring the cost down.
Avatar
Essen 2025-09-13 1:11 p.m.
Here are my initial thoughts :
  • ~1mm2 area
  • 6 pins : 4 digital ( 1 IO, 2 I, 1 O), 1 power, 1 gnd
1:14 p.m.
I would also need bonding, but am willing to take care of organizing and coordinating it ( have never done it )
