@Tim Edwards, @Tholin had some questions / thoughts about analog stuff on GF180MCU.

Not really questions as much as I just wanna mess around and find out with some analog circuits on my next GF180 tapeout.

Sure, analog IP is yet another need for GF180MCU. I would take a look at what's being produced for Chipathon. I have been running my own track so I haven't been looking at what the analog groups have been doing, but for the record, you can find the Chipathon discussions on fossi-chat.org under the "Chipathon 2025" channel, or on github at https://github.com/sscs-ose/sscs-chipathon-2025/issues.

There is a bunch of interesting information in the Chipathon page @ https://github.com/sscs-ose/sscs-chipathon-2025/tree/main/resources/Integration

sscs-chipathon-2025/resources/Integration at main · sscs-ose/sscs-...

Blocks & Bots: An Open Chip Playground augmented with LLMs. Please check: https://sscs.ieee.org/technical-committees/tc-ose/sscs-pico-design-contest/ - sscs-ose/sscs-chipathon-2025

2

@Tim 'mithro' Ansell : If nothing else, Chipathon 2025 is surfacing a number of issues in the GF180MCU open PDK that needed to be addressed, and they are getting fixed, which will definitely benefit you and wafer.space for the first shuttle run.

Tim Edwards

@Tim 'mithro' Ansell : If nothing else, Chipathon 2025 is surfacing a number of issues in the GF180MCU open PDK that needed to be addressed, and they are getting fixed, which will definitely benefit you and wafer.space for the first shuttle run.

Yeap! You know I'm a big believer that quality is related to the number of users.
