xianglin_pu 04/02/2026 01:40
We have designed our own COB PCB based on Andrew Wingate's orginal design (we re-routed some traces and add an additional "mosbius" logo). The design is finalized. Currenly the design files are stored in our GitHub repo: https://github.com/mosbiuschip/WaferSpace_COB_70pins/tree/xp/V3_COB_Original/V3_COB_Original However I did not find the place to submit the PCB files (gerber & drill), could anyone suggest where can this file be managed ? (also any suggestions to our PCB are appreciated) Many Thanks !
WaferSpace_COB_70pins/V3_COB_Original/V3_COB_Original at xp · mosb...
PCB design for COB packaging through wafer.space. Contribute to mosbiuschip/WaferSpace_COB_70pins development by creating an account on GitHub.
Thumbnail
Avatar
Tim 'mithro' Ansell 04/03/2026 00:34
FYI - @Andrew Wingate
Avatar
Andrew Wingate 04/03/2026 05:18
Hey @xianglin_pu Looks pretty good. I don't think we have anything formalized yet for submission and will likely be handled specifically as there aren't many versions for now. I made a link for easy viewing on kicanvas Thanks for the update, I will keep you informed when/if we need anything else. Thanks
Avatar
xianglin_pu 04/04/2026 01:41
Hi @Andrew Wingate thanks for the information. Let me know when it’s ready so I may work with you submitting the files.
