Information / questions / Detailed Routing Antenna Violation
Between 11/30/2025 23:59 and 01/01/2026 00:00
Avatar
Trevor Peyton 12/03/2025 15:21
I've tried doing 20+ iterations on the detailed routing antenna fixing, and I have a single stubborn net/pin violation. + check_antennas [INFO ANT-0002] Found 1 net violations. [INFO ANT-0001] Found 1 pin violations. Even after 40 total iterations, it will not fix this. Does anyone know how I can figure out what net/pin this is and possibly how I could fix this?
Avatar
Clyde Laforge 12/03/2025 17:07
I had somewhat similar issues on klayout where it was not clear where the error was coming from. Safest way to proceed was to copy the part of the design that failed, and cut connections until the error was gone
Avatar
Avatar
Trevor Peyton
I've tried doing 20+ iterations on the detailed routing antenna fixing, and I have a single stubborn net/pin violation. + check_antennas [INFO ANT-0002] Found 1 net violations. [INFO ANT-0001] Found 1 pin violations. Even after 40 total iterations, it will not fix this. Does anyone know how I can figure out what net/pin this is and possibly how I could fix this?
Leo Moser (mole99) 12/03/2025 20:06
The antenna summary should show you the affected net/pin. LibreLane allows you to manually insert antenna diodes: ... substituting_steps: +OpenROAD.DetailedRouting: Odb.InsertECODiodes ... INSERT_ECO_DIODES: - target: instance/pin
Avatar
Trevor Peyton 12/03/2025 20:11
Less is more I guess. Either I had a stubborn pin or something else, I ran it with only 10 iterations and it stopped after 6 and says it's all clear.
