tnt 10/01/2025 21:00
The specs for diffusion / poly have specs for both salicided and non-salicided version. Can anyone confirm the default is that those will receive salicide except where the SAB layer is drawn ? ( I'm kind of guessing SAB is "SAlicide Block" )
Avatar
Avatar
tnt
The specs for diffusion / poly have specs for both salicided and non-salicided version. Can anyone confirm the default is that those will receive salicide except where the SAB layer is drawn ? ( I'm kind of guessing SAB is "SAlicide Block" )
htamas 10/01/2025 21:51
Yes, it's salicide block: https://gf180mcu-pdk.readthedocs.io/en/latest/physical_verification/design_manual/drm_04_3.html
Avatar
Tim 'mithro' Ansell 10/01/2025 22:39
@Tim Edwards - I believe @htamas is correct here?
Avatar
Tim Edwards 10/01/2025 22:41
Yes.
Avatar
tnt 10/02/2025 05:24
Thanks
